Slam-It™ Split Drive Anchor Mechanical Anchors Wej-It

Roll over image to zoom in

Slam-It™ Split Drive Anchor

This anchor is a one-piece, pre-formed, tamper-proof anchor ideal for anchoring into solid concrete and stone.

Pack Price

$12.00

Quantity

USA

ENGINEERED IN THE USA
Ships Fast within 24 hours
Orders received before 2:00pm EST Monday through Friday usually ship the same business day. We will send an email confirming your order the day your order is received. When your order ships we will send you a second email with your paid invoice and information to track your order.

Materials / Finishes

  • Zinc-plated carbon steel
  • Mechanically galvanized

Features and Benefits

  • One-piece anchor is easy to install
  • Tamper-proof
  • Works in concrete and stone
  • Two head styles available
    • Flat head is best for wood-to-concrete applications – can be removed for temporary applications
    • Mushroom head allows fast and clean permanent installations
  • The unique split feature is compressed during installation; after installation it re-expands, exerting force against the walls of the hole resulting in high holding values

Downloads

Technical Flyer

Product Details
Installation
Catalog Number
Head Style
Material
Anchor Size
Drill Bit Dia.
Box Quantity
Carton Quantity
SDF1412
Flat Head
Carbon Steel
1/4 x 1-1/2
1/4
100
800
SDF1420
Flat Head
Carbon Steel
1/4 x 2
1/4
100
800
SDF1422
Flat Head
Carbon Steel
1/4 x 2-1/2
1/4
100
800
SDF1430
Flat Head
Carbon Steel
1/4 x 3
1/4
100
800
SDF1432
Flat Head
Carbon Steel
1/4 x 3-1/2
1/4
100
800
SDF1440
Flat Head
Carbon Steel
1/4 x 4
1/4
100
800
SDR1412
Mushroom Head
Carbon Steel
1/4 x 1-1/2
1/4
100
800
SDR1420
Mushroom Head
Carbon Steel
1/4 x 2
1/4
100
800
SDR1422
Mushroom Head
Carbon Steel
1/4 x 2-1/2
1/4
100
800
SDFG1430
Flat Head
Galvanized
1/4 x 3
1/4
100
800

  1. Drill hole in masonry or concrete through mounting holes in fixture same diameter as anchor to be used. Clean hole using compressed air and a nylon brush. A clean hole is necessary for proper performance.
  2. Insert anchor through mounting holes in fixture and into anchor hole.
  3. Tap gently until head of anchor body is set tightly against item to be fastened. Gently hammer pin flush to expand body. Do not over-drive pin into body as this could damage the anchor.

NOTE: Always wear safety glasses. Follow drill manufacturer's instructions. Use only solid carbide-tipped drill bits meeting ANSI B212.15 diameter standards.
