Channel Slots (130)

Channel slots are welded to structural columns or attached with fasteners using the two holes on the face for adjustable attachment of masonry to backup structures. They can also be used to replace dovetail anchor systems for concrete walls that were not cast with dovetail slots. Use with Channel Slot Anchors.

Pack Price

$430.00

Quantity

USA

ENGINEERED IN THE USA
Special Order - Ships Fast
Special order items are usually shipped within 1-5 days. Please contact us for an updated lead time. In most cases items are in stock. If an item is out of stock we can produce the part quickly for your project. When you place an order, we will notify you immediately with an updated lead time.

Materials / Finishes

Open Icon Close Icon
  • Plain Steel
  • Mill Galvanized
  • Hot-Dip Galvanized After Fabrication
  • 304 Stainless Steel

Features and Benefits

Open Icon Close Icon
  • Attach to structural columns or beams
  • Various Channel Slot Anchors are inserted into the slot for vertical adjustment
  • 11 and 16 gauge thicknesses
  • Length: 8”
  • 1-3/8” wide
  • Slot opening is 9/16”

Downloads

Open Icon Close Icon

 Specification PDF
 Specification Doc
 Submittal Sheet
 2D CAD details
 3D CAD details

Product Details
Installation
Catalog No.
Material
Thickness (gage)
Length (in.)
Box Quantity
130-11P
Plain Steel
11
8
75
130-16P
Plain Steel
16
8
100
130-11G
Mill Galvanized
11
8
75
130-16G
Mill Galvanized
16
8
100
130-11H
Hot-Dip Galvanized
11
8
75
130-16H
Hot-Dip Galvanized
16
8
100
130-11S
304 Stainless Steel
11
8
75
130-16S
304 Stainless Steel
16
8
100

Channel Slots:
Weld 1-1/2 inches (38.1 mm) on both sides at the top and the bottom of the anchor.

Ties:
Insert tie into channel and rotate 90 degrees.
