Corrugated Notch Column Anchor (196) Veneer Anchoring System Heckmann

Roll over image to zoom in

Corrugated Notch Column Anchor (196)

The Corrugated Notch Column Anchor is used to anchor masonry walls to structural steel beams where the column flanges are parallel to the masonry wall. 1” deep x 5/8” wide notch clips onto the steel beam flange for a secure installation. Order by piece. Anchors are reversible for left or right side use.

Pack Price

$125.00

Quantity

USA

ENGINEERED IN THE USA

Special Order - Ships Fast
Special order items are usually shipped within 1-5 days. Please contact us for an updated lead time. In most cases items are in stock. If an item is out of stock we can produce the part quickly for your project. When you place an order, we will notify you immediately with an updated lead time.

Materials / Finishes

  • Mill Galvanized
  • 304 Stainless Steel
  • Hot-dip Galvanized After Fabrication

Features and Benefits

  • Attaching masonry walls to structural steel beams
  • Order by piece, anchor is reversible for left or right side use
  • Standard size: 7” L x 2” W, 1/8” thick
  • Standard corrugated section: 4-1/2”
  • Standard notch: 5/8” x 1”, 1” from end of anchor
Product Details
Installation
Catalog No.
Material
Thickness (in.)
Width (in.)
Length (in.)
Box Quantity
196-G
Mill Galvanized
1/8
2
7
50
196-H
Hot-Dip Galvanized
1/8
2
7
50

Install as specified in applicable masonry section(s).
