Corrugated Wall Tie (260)

Used to bond masonry veneer to a wood frame backup wall with maximum 1" airspace. These are permitted only on wood backup walls. Note: TMS402/ACI530 Building Code allows corrugated wall ties in walls with a maximum airspace of 1". for larger airspaces, use the Corrugated Brick Veneer Anchor with Hole (187).

Pack Price

$300.00

Quantity

USA

ENGINEERED IN THE USA
Special Order - Ships Fast
Special order items are usually shipped within 1-5 days. Please contact us for an updated lead time. In most cases items are in stock. If an item is out of stock we can produce the part quickly for your project. When you place an order, we will notify you immediately with an updated lead time.

Materials / Finishes

Open Icon Close Icon
  • 304 Stainless Steel

Features and Benefits

Open Icon Close Icon
  • Secure masonry veneer to wood frame backup wall
  • Allows maximum airspace of 1”
  • Standard size: 7”long x 7/8” wide
  • Standard thickness: 22 gauge
  • Custom sizes available

Downloads

Open Icon Close Icon

 Specification PDF
 Specification Doc
 Submittal Sheet
 2D CAD details
 3D CAD details

Product Details
Installation
Catalog No.
Material
Thickness (Gage)
Width (in.)
Length (in.)
Box Quantity
26016S
304 Stainless Steel
16
7/8
7
300
26018S
304 Stainless Steel
18
7/8
7
300
26020S
304 Stainless Steel
20
7/8
7
500
26022S
304 Stainless Steel
22
7/8
7
500

Install as specified in applicable masonry section(s).
