Double Pintle Wire Tie (282)

Used in conjunction with the Double Pintle Plate Veneer Anchors (213)

Wire Ties are 3/16" diameter and allow 1-1/4" vertical adjustment in the 213 plate anchor.



Pack Price

$175.00

Quantity

USA

ENGINEERED IN THE USA
Special Order - Ships Fast
Special order items are usually shipped within 1-5 days. Please contact us for an updated lead time. In most cases items are in stock. If an item is out of stock we can produce the part quickly for your project. When you place an order, we will notify you immediately with an updated lead time.

Materials / Finishes

Open Icon Close Icon
  • Hot-Dip Galvanized After Fabrication

Features and Benefits

Open Icon Close Icon
  • Used with #213 Double Pintle Plate Veneer Anchors
  • Attaches directly to the backup system
  • 3/16" diameter, in lengths of: 3-1/4", 4-1/4", and 5-1/4"
  • Works with the following insulation thicknesses:
    • No insulation, 1", 1-1/2", 2", 2-1/2", 3", 3-1/2", 4"

Downloads

Open Icon Close Icon

 Specification PDF
 Specification Doc
 Submittal Sheet

Product Details
Installation
Catalog No.
Material
Diameter (in.)
Length (in.)
Box Quantity
2823H
Hot-Dip Galvanized
3/16
3-1/4
350
2824H
Hot-Dip Galvanized
3/16
4-1/4
350
2825H
Hot-Dip Galvanized
3/16
5-1/4
350

Install as specified in applicable masonry section(s).
