Dovetail Corrugated Anchor (106) Veneer Anchoring Systems Masonry to Concrete Heckmann

Roll over image to zoom in

Dovetail Corrugated Anchor (106)

For attaching brick veneer to concrete backup walls installed with #100 dovetail anchor slot.

Pack Price

$60.00

Quantity

USA

ENGINEERED IN THE USA
Special Order - Ships Fast
Special order items are usually shipped within 1-5 days. Please contact us for an updated lead time. In most cases items are in stock. If an item is out of stock we can produce the part quickly for your project. When you place an order, we will notify you immediately with an updated lead time.

Materials / Finishes

Open Icon Close Icon
  • Mill Galvanized
  • Hot-dip Galvanized After Fabrication
  • 304 Stainless Steel

Features and Benefits

Open Icon Close Icon
  • For attaching brick veneer to concrete backup walls with #100 dovetail anchor slot.
  • Standard thickness: 16 gauge or 12 gauge
  • 1" wide in lengths of 3-1/2", 5-1/2", and 7-1/2"

Downloads

Open Icon Close Icon

 Specification PDF
 Specification Doc
 Submittal Sheet
 2D CAD details
 3D CAD details

Product Details
Installation
Catalog No.
Material
Thickness (gage)
Width (in.)
Length from face of concrete (in.)
Box Quantity
106123G
Mill Galvanized
12
1
3-1/2
250
106125G
Mill Galvanized
12
1
5-1/2
200
106127G
Mill Galvanized
12
1
7-1/2
150
106163G
Mill Galvanized
16
1
3-1/2
250
106165G
Mill Galvanized
16
1
5-1/2
250
106167G
Mill Galvanized
16
1
7-1/2
250
106123H
Hot-Dip Galvanized
12
1
3-1/2
250
106125H
Hot-Dip Galvanized
12
1
5-1/2
200
106127H
Hot-Dip Galvanized
12
1
7-1/2
150
106163H
Hot-Dip Galvanized
16
1
3-1/2
250
106165H
Hot-Dip Galvanized
16
1
5-1/2
250
106167H
Hot-Dip Galvanized
16
1
7-1/2
250
106123S
304 Stainless Steel
12
1
3-1/2
250
106125S
304 Stainless Steel
12
1
5-1/2
200
106127S
304 Stainless Steel
12
1
7-1/2
150
106163S
304 Stainless Steel
16
1
3-1/2
250
106165S
304 Stainless Steel
16
1
5-1/2
250
106167S
304 Stainless Steel
16
1
7-1/2
250

Install as specified in applicable masonry section(s).
