Lag Screw Shield

Our corrosion-resistant Lag Screw Shield can be used in concrete, masonry, and mortar joints. Our long version increases holding values, and the short version is recommended in harder masonry for reduced drilling time.

Pack Price

$10.40

Quantity

USA

ENGINEERED IN THE USA

Ships Fast within 24 hours
Orders received before 2:00pm EST Monday through Friday usually ship the same business day. We will send an email confirming your order the day your order is received. When your order ships we will send you a second email with your paid invoice and information to track your order.

Materials / Finishes

  • Zamac alloy

Features and Benefits

  • Ideal for use in concrete, masonry and mortar joints
  • Available in short and long lengths for different situations
  • Bolt can easily be removed during service work without replacing the anchor

Downloads

Product Details
Installation
Catalog Number
Style
Drill Bit Dia.
Thread Size
Anchor Length
Box Quantity
Carton Quantity
LSS14
Short
1/2
1/4 - 10
1
50
1000
LSS56
Short
1/2
5/16 - 9
1-1/4
50
1000
LSS38
Short
5/8
3/8 - 7
1-3/4
50
500
LSS12
Short
3/4
1/2 - 6
2
25
250
LSS58
Short
7/8
5/8 - 5
2
25
250
LSL14
Long
1/2
1/4 - 10
1-1/2
50
1000
LSL56
Long
1/2
5/16 - 9
1-3/4
50
1000
LSL38
Long
5/8
3/8 - 7
2-1/2
50
400
LSL12
Long
3/4
1/2 - 6
3
25
250
LSL58
Long
7/8
5/8 - 5
3-1/2
25
250

  1. Drill the hole according to the "Drill Dia." shown on the Performance Data Charton the Tech Specs tab. To assure full holding power, do not ream the hole or allow the drill to wobble.
  2. Drill the hole deeper than the intended embedment, but not closer than two diameters to the bottom (opposite) surface of the concrete.
  3. Clean the hole with a nylon brush and compressed air.
  4. Insert anchor into the hole and tap flush.
  5. Position fixture, insert bolt and tighten.

NOTE: Always wear safety glasses. Follow drill manufacturer's safety instructions. Use only solid carbide-tipped drill bits meeting ANSI B212.15 diameter standards.
