Screw-In™ Drive Screw Anchor Mechanical Anchors Wej-It

Roll over image to zoom in

Screw-In™ Drive Screw Anchor

This pre-assembled two -piece drive screw anchor is comprised of a corrosion-resistant zamac alloy anchor body and a removable steel Phillips head screw. The screw can be easily removed after the anchor is properly set. Screw-in Drive Screw Anchors are ideal for light-duty applications in concrete, block, stone, or brick.

Pack Price

$11.60

Quantity

USA

ENGINEERED IN THE USA

Ships Fast within 24 hours
Orders received before 2:00pm EST Monday through Friday usually ship the same business day. We will send an email confirming your order the day your order is received. When your order ships we will send you a second email with your paid invoice and information to track your order.

Materials / Finishes

  • Body: diecast zamac alloy anchor
  • Screw: zinc-plated carbon steel

Features and Benefits

  • Versatile, general purpose anchor
  • Removable steel #2 Phillips head screw
  • Pre-assembled —one-step, ready to use
  • Screw can be easily removed after anchor is properly set

Downloads

Product Details
Installation
Catalog Number
Anchor Size
Drill Bit Dia.
Screw Style
Box Quantity
Carton Quantity
DNHS1403
1/4 x 3/4
1/4
#2 Phillips
100
1000
DNHS1410
1/4 x 1
1/4
#2 Phillips
100
1000
DNHS1411
1/4 x 1-1/4
1/4
#2 Phillips
100
1000
DNHS1412
1/4 x 1-1/2
1/4
#2 Phillips
100
800
DNHS1420
1/4 x 2
1/4
#2 Phillips
100
800
  1. Drill the hole perpendicular to the work surface at least 1/4” deeper than the calculated embedment depth. Clean the hole using compressed air and a nylon brush.
  2. Insert anchor assembly through mounting holes in fixture and into anchor hole.
  3. Gently hammer screw flush to expand body.

To remove: Using a Phillips screw driver, turn counter clockwise until screw is removed from anchor body. Set the claw of a hammer between the anchor body and fixture and pull loose.
