Strike-It™ Center Pin Drive Anchor Mechanical Anchors Wej-It

Roll over image to zoom in

Strike-It™ Center Pin Drive Anchor

This pre-assembled impact pin drive anchor is designed for medium and heavy-duty anchoring into concrete and grout-filled block. With its unique all-in-one serrated nut and washer, it offers vibration resistance and superior holding. ALL AMERICAN ANCHOR EQUIVALENT

Pack Price

$75.70

Quantity

USA

ENGINEERED IN THE USA
Ships Fast within 24 hours
Orders received before 2:00pm EST Monday through Friday usually ship the same business day. We will send an email confirming your order the day your order is received. When your order ships we will send you a second email with your paid invoice and information to track your order.

Materials / Finishes

  • Hot rolled steel anchor body with a hot wrought iron pin
  • Zinc-plated

Features and Benefits

  • Serrated hex washer nut provides optimal vibration resistance
  • Ribbed anchor point increases friction with internal walls of the predrilled hole
  • Suitable for solid base materials
  • Easy to install
  • No wrench needed
  • Anchor tensions itself automatically
  • Easy to inspect: anchor is set after center pin is hammered down to meet the threads and is flush with the top of the bolt

Downloads

Technical Flyer

Product Details
Installation
Catalog Number
Anchor Size
Thread Length
Drill Bit Dia.
Box Quantity
Carton Quantity
CP1413
1/4 x 1-3/4
5/8
1/4
100
800
CP1423
1/4 x 2-3/8
3/4
1/4
100
800
CP5620
5/16 x 2
3/4
5/16
100
800
CP5623
5/16 x 2-3/4
1
5/16
100
800
CP3823
3/8 x 2-3/8
1
3/8
50
400
CP3832
3/8 x 3-1/2
1-1/4
3/8
50
400
CP3843
3/8 x 4-3/4
1-3/8
3/8
50
400
CP1223
1/2 x 2-3/4
1
1/2
25
200
CP1232
1/2 x 3-1/2
1-1/4
1/2
25
200
CP1243
1/2 x 4-3/4
1-3/4
1/2
25
200
CP1260
1/2 x 6
2
1/2
25
200
CP5840
5/8 x 4
1-1/2
5/8
10
80
CP5860
5/8 x 6
2
5/8
10
80
CP3450
3/4 x 5
2
3/4
10
30
CP3460
3/4 x 6
2
3/4
10
30
CP3472
3/4 x 7-1/2
2
3/4
10
30

  1. Drill the hole perpendicular to the work surface. To assure full holding power, do not ream the hole or allow drill to wobble. Clean hole using compressed air and a nylon brush. A clean hole is necessary for proper performance.
  2. Preset the nut and washer for desired embedment.
  3. Hammer center pin until it is aligned with the top of the bolt.
  4. Tighten nut.

NOTE: Always wear safety glasses. Follow drill manufacturer's instructions. Use only solid carbide-tipped drill bits meeting ANSI B212.15 diameter standards.
