Ankr-TITE® Wedge Anchor- Zinc-Plated Carbon Steel Mechanical Anchors Wej-It

Roll over image to zoom in

Ankr-TITE® Wedge Anchor — Zinc-Plated Carbon Steel

This pre-assembled high strength, fully threaded, and torque-controlled expansion wedge anchor has a unique safety shoulder in the expansion cone that supports a thick 3-dimple clip engineered to provide high load carrying capability and reduce slip in a variety of installation conditions. Nut and washer included.


Pack Price

$18.50

Quantity

USA

ENGINEERED IN THE USA
Ships Fast within 24 hours
Orders received before 2:00pm EST Monday through Friday usually ship the same business day. We will send an email confirming your order the day your order is received. When your order ships we will send you a second email with your paid invoice and information to track your order.

Materials / Finishes

Available in:
Hot-Dip Galvanized Steel
304 Stainless Steel
316 Stainless Steel
Zinc Plated Carbon Steel

Features and Benefits

  • Length and identification code stamped on head to ease identification pre and post-installation
  • Dog-point head prevents point damage during installation
  • Fully threaded anchor body accommodates various application thickness
  • Enlarged 3-dimple clip
    • Increases response in lightweight concrete and requires fewer rotations to achieve desired torque
    • 360 º segment contact on clip equalizes load distribution and increases load-carrying capacity
  • Unique safety shoulder
    • Supports the 3-dimple clip under maximum and ultimate loads, preventing slippage
    • Similar products have gradual expansion cone that does NOT have a safety shoulder to support the clip when anchor is under strain

Downloads

Technical Flyer

Product Details
Installation
Catalog Number
Anchor Size
Min. Embed.
Thread Length
Box Quantity
Carton Quantity
AT1413
1/4 x 1-3/4
1-1/4
3/4
100
800
WTW1421 (Tie-Wire)
1/4 x 2-1/4
1-1/4
-
100
1000
AT1421
1/4 x 2-1/4
1-1/4
1-1/4
100
800
AT1431
1/4 x 3-1/4
1-1/4
2-1/4
100
800
AT3821
3/8 x 2-1/4
1-3/4
1
50
400
AT3823
3/8 x 2-3/4
1-3/4
1-1/2
50
400
AT3830
3/8 x 3
1-3/4
1-3/4
50
400
AT3833
3/8 x 3-3/4
1-3/4
2-1/2
50
400
AT3850
3/8 x 5
1-3/4
3-1/4
50
400
AT3870
3/8 x 7
1-3/4
4-1/2
50
300
AT1223
1/2 x 2-3/4
2-1/8
1-1/8
25
200
AT1233
1/2 x 3-3/4
2-1/8
2-1/8
25
200
AT1241
1/2 x 4-1/4
2-1/8
2-5/8
25
200
AT1242
1/2 x 4-1/2
2-1/8
2-5/8
25
200
AT1252
1/2 x 5-1/2
2-1/8
3-3/4
25
150
AT1270
1/2 x 7
2-1/8
4-1/2
25
150
AT1282
1/2 x 8-1/2
2-1/8
5
10
40
AT1210
1/2 x 10
2-1/8
5
10
40
AT1212
1/2 X 12
2-1/8
5
10
40
AT5832
5/8 x 3-1/2
2-5/8
1-1/2
10
80
AT5841
5/8 x 4-1/4
2-5/8
2-3/8
10
80
AT5842
5/8 x 4-1/2
2-5/8
2-5/8
10
80
AT5850
5/8 x 5
2-5/8
3-1/8
10
80
AT5860
5/8 x 6
2-5/8
4
10
80
AT5870
5/8 x 7
2-5/8
4-1/2
10
80
AT5882
5/8 x 8-1/2
2-5/8
5
10
40
AT5810
5/8 x 10
2-5/8
5
10
40
AT5812
5/8 x 12
2-5/8
5
10
40
AT3441
3/4 x 4-1/4
3-1/4
2
10
80
AT3443
3/4 x 4-3/4
3-1/4
2-1/2
10
80
AT3452
3/4 x 5-1/2
3-1/4
3-1/4
10
60
AT3461
3/4 x 6-1/4
3-1/4
3-3/4
10
60
AT3470
3/4 x 7
3-1/4
4-3/4
10
60
AT3482
3/4 x 8-1/2
3-1/4
5
10
40
AT3410
3/4 x 10
3-1/4
5
10
40
AT3412
3/4 x 12
3-1/4
5
5
20
AT7860
7/8 x 6
3-1/4
3-1/2
5
30
AT7880
7/8 x 8
3-7/8
5
5
20
AT7810
7/8 x 10
3-7/8
5
5
20
AT1060
1 x 6
4
3
5
30
AT1090
1 x 9
4
5
5
20
AT1012
1 x 12
4
5
5
20
AT11490
1-1/4 x 9
5-5/8
5
4
12
AT11412
1-1/4 x 12
5-5/8
5
4
12

  1. Drill the hole, whose diameter equals the anchor diameter, perpendicular to the work surface. To assure full holding power, do not ream the hole or allow the drill to wobble.
    Drill the hole deeper than the intended embedment, but not closer than two diameters to the opposite surface of the concrete.
  1. A clean hole is necessary for proper performance. Clean the hole using a nylon brush and compressed air.
  2. Assemble the nut and washer onto the anchor. Drive the anchor through the material to be fastened at the calculated embedment depth.
  3. Tighten the nut, or head, 3 to 5 turns past the hand tight position. Installing with a torque wrench is recommended for optimum performance. Refer to Recommended Setting Torque* in the table below.

NOTE: Always wear safety glasses. Follow drill manufacturer's instructions. Use only solid carbide- tipped drill bits meeting ANSI B212.15 diameter standards.
